Industrial 2D Image desktop scanner
Product Name:
Industrial 2D Image desktop scanner
:
:
:


Product Description

 NW-460 Industrial 2D Image desktop scanner


Features:

The new 32-bit decoder chip. Interpretation  of various one-dimensional code / two-dimensional code

Plug and play, set up simple, can be quickly used with other office equipment

bit error rate as low as 1/500 million times, accurate and correct



with touch button



professional  and technical, can scan WeChat, Alipay bar code

wire core using 0.01 mm copper wire each 28 core 1), containing pull- pull nylon thread, longer than the ordinary wire rod life

wire using antifreeze material, can be used at minus 30 degrees outside the ambient temperature



Application  areas



Mainly used in the super, stores, warehousing,  WeChat / Alipay payment, airport / high-speed rail, ticket (sports) areas

Specification:



Model Number

NW-460

Performance  Parameters

Light Sources

617nm LED single dot, white LED



Supported Symbologies













Postal

1D:UPC/EAN,ISSN,UCC Coupon Extended Code,Code128,GS1-128,ISBT

128,Code39,Code93 FullASCII,Trioptic Code39,Code32,Code11,Matrix 2 of

5,Interleaved  2 of 5,Discrete 2 of 5,Codebar,MSI, Chinese 2 of 5,GS1 Databar

Variants,Korean 3 of 5,ISBT Concat.

2D:PDF417,MicroPDF417,Composite Codes,TLC-39,Data Matrix,Maxi code,QR Code,Micro QR,Aztec.

U.S. Posnet and planet,U.K. Post, Japan Post,Australian Post,Netherlands KIX Code,Royal Mai 4 state Customer,UPU FICS 4 state Postal,USPS  4CBl

Optical System

752 H x 480 V pixels (Wide VGA)

Resolution

4 mil (Code 39), 7.5 mil (Data Matrix), 5 mil (PDF 417)

Focusing Distance

Up to 267mm

Field of View

Horizontal: 46.1°; Vertical: 30.4°

Indicator

LED, Speaker

Interfaces

USB HID/USB-COM/RS-232

Physical Parameters

Dimensions

96mm*108mm*150mm

Weight

320g

Material

ABS+PC

Cable Length

2M



Environmental Parameters

Operating Temperature

-20 °C to 50 °C (32oF to 104oF)

Storage Temperature

-40~70

Relative Humidity

0%~95% RH(non-condensing/non-freezing)

Drop/Shock Resistance

Withstands multiple times 1.5 meters drops to concrete

Electrical Parameters

Voltage

DC5V±10%

Current

4000mA
